Sector 7 Launch X-431 PAD V Obd Scanner Wifi BT Automotive Truck Key Programmer Diagnostic Tool Set For Car

  • $7,999.47
    Unit price per


Details Images
Tablet size
10.1 inches, 1920 * 1200, fully laminated, sunlight readable screen (Gorilla Glass)
System version
Android 7.1
CPU version
Qualcomm MSM8953 2.0GHz octa-core
Running memory
4GB
Storage memory
64GB, supports expansion 128GB
Battery capacity
3.8V/9360mAh, support QC3.0 fast charging, listed companies provide
Camera
front 800W, rear 1300W
Wifi network
2.4GHz, 5Ghz dual-band, support dual WiFi
Tablet size
320 x 211 x 46 (mm)
Tablet restrictions
Only original tablet can be used, no third party support.
Software restrictions
can not install third-party software
Diagnostic level
full system advanced diagnosis + programming
APP language
follow the system
Product Description
Feature
1. Android 7.1 customized system, Qualcomm 8-core processor, 10.1 inch capacitive touch screen, support QC3.0 fast charging.
2. 2.4GHz&5GHz Dual-Frequency Wi-Fi, the transmission rate is faster than the previous generation.
3. Support commercial vehicle and passenger car diagnose, Support J2534, CAN FD, DoIP.
4. Wide mode coverage, powerful and a large number,of diagnostic functions, and accurate test data.
5. Brand new industrial design, with soft rubber sheath on the four corners of the product, to effectively prevent collision;
damping shaft, free adjustment of nearly 180 degrees; support three modes of hanging, support and normal.

Function
1. Comprehensive diagnosis: Support full-make, full-system, full-function rapid diagnosis, read DTC, clear DTC, read data stream,
actuation test, etc.
2. Intelligent diagnose: Support intelligent VIN identification and cloud-based diagnostic record query, making the diagnostics
more intelligent and efficient.
3. Local diagnose: When the intelligent diagnosis is not available in an environment without network, choose traditional
diagnosis. Select the vehicle make and model manually to perform the vehicle detection.
4. Remote diagnose: Support online real-time communication and remote diagnostic service through text, picture, and file between device and device, and between device and remote desktop, with low network bandwidth and system resources occupancy.
5. Special function: Support total 16 special functions, including service lamp reset, throttle adaptation, steering angle reset, brake pad reset, tire pressure reset, anti-theft matching, ABS bleeding, battery matching, gear learning, injector coding, DPF regeneration, sunroof initialization, headlamp matching, suspension matching and AT matching, EGR Adaption.
6. Software upgrade: Support one-click upgrade of operation system, client side, car model software and firmware.
7. Diagnostic feedback: For model software and function errors met during the use, please submit the feedback immediately. LAUNCH will response as soon as possible.
8. My report: View comprehensive diagnostic report, remote diagnostic report, and data stream playback.
9. Settings: Contains my connector, diagnostic connector connection management, connector activation, firmware repair, etc.
10. Extended module: Support oscillograph, sensor, battery test, endoscope, Wi-Fi printer, etc.
LAUNCH X431 PAD V is the Top Recommended by auto repair shops and mechanics!!!

The Advantage Function of LAUNCH X431 PAD V - J2534 Online Programming :

LAUNCH X431 PAD V supports programming and coding, which is to write the relevant control information of the software into the automotive computer's programmable EPROM or FLASH by making use of the electronic communication transmission technology.

Use LAUNCH X431 PAD V to online prgoramming function , it is more safty and very fast , even though you failed during programming , x431 pad v can allow you program again , will not break the ECU.

This function is required only if any of the following scenarios occur:

1)A new ECU is replaced;

2) The ECU doesn't work properly;

3) The ECU is required to update the software version;

4)After the vehicle completes routine self-diagnosis (read and clear DTCs, read data streams, andactuation tests), its malfunction still exists.

LAUNCH X431 PAD V Support intelligent recognition of programming files, convenient and quick operation. Support for Mercedes-Benz, for Benz New Energy, for BMW, for BMW New Energy, for GM, General New Energy, for Ford,Ford New Energy, for Volkswagen, for Volkswagen New Energy, for Audi, for Audi New Energy, for Land Rover, for Nissan,Skoda, for Seat, for Mazda and other models Programming function.

LAUNCH X431 PAD V works Smartbox V3.0 diagnose connector , it supports All diagnostic protocols : J2534 protocol + D-PDU protocol + RP1210 protocol + CANFD+DOIP protocol

What is more , LAUNCH X431 PAD V is the only one support DOIP/CANFD protocol in the market until now , and it also For 2017 and Later FCA Vehicles with Secure Gateway Module (SGW) ( To America area , the function is free , to European area , the function need subscibe in offical website first )

Note :

1. the function need contact us to active first , then you can use it .
2. the Function does not work in Spain & North America ( except for Nissan and for Infinite cars ) .
